Switch worked perfictaiy was the right replacment. Thank you

Thank you!!!

I recently completed a restoration project on my, “old-school”, Sears 30A, 6&12V Battery Charger using the 697012 rotary switch I ordered from PLP BATTERY SUPPLY-(It arrived in 4 days).
The four primary windings of the transformer had to be identified and marked, verifying their incremental progression as it pertains to the transformer’s secondary output voltage, from lowest to highest-this is the best way to know how to connect them to to switch in the same progression from terminals 2-4-6-8, in that order.

The original mounting hole was not round but was easily corrected with a 7/16” drill bit. The next challenge was to drill two, additional holes adjacent to the 7/16” hole for the two, switch anti-rotation tabs. This was not that easy to mark while paying close attention to the orientation of the knob pointer. So, I focused on keeping pointer on switch position 3, (at the twelve o’clock position), and then marking the two holes for the tabs. This made all the other switch positions line up perfectly with the various lines marked on the front panel. After a few minor adjustments, the tabs came through the front panel perfectly with the knob’s pointer straight up in position 3 and then I installed the mounting hardware to make it secure.

It took some time and patience to make this all happen-but afterwards, I was so pleased with the results! Anything worth doing is worth doing right-my thanks again to PLP for continuing to make these types of quality, OEM replacement parts available to keep our vintage electrical equipment running perfectly for years!
Rob G

Works great

Great prices and fast delivery

works perfect as I choose the horizontal switch because of a tight engine hood

Diodes work great and thank you for the six that you sent me I really appreciate that I will call you back in the future next time I need something thank you

The product was a great fit and the instructions made it easy to follow.Switch works as promised.

They helped identify what rectifier I needed and shipped it out the same day. The rectifier worked with a little trimming on the heat sink plate and got my 40 year old battery charger working again. It saved me from buying a new charger.

697015 - Power Forged Battery Charger Switch Kit - 8-Position Replaces Associated Eqpt 611187

I checked my battery charger and determined that it needed a $23.00 part, so I ordered the part it came in a few days and I installed it in a few minutes and the charger is working like new.

SED® Gray Plastic T-Handle for Industrial Connectors - Anderson SB Connector Compatible

696021 - Universal AC Cooling Fan Kit - Includes Motor, Fan Blade & Mounting Hardware Replaces Associated Eqpt 610190

696366 - Switch Kit - 2-Position Slide Switch (3 terminal) - replaces Schumacher 0499000032

Great part and perfect fit , thank you
